AC Induction/NEMA
X$D Ultra® Extra Severe Duty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
X$D Ultra® 841 Extra Severe Duty
- Power: 0.75–300 HP
- Speed: 900–3600 RPM
- Voltage: 230/460, 460, 575 V
- Frequency: 60 Hz
- Alternate 50 Hz data on nameplate
- TEFC (IP55)
- Frame sizes: 143T–449T
- NEMA, CSA, IEEE 45, IEEE 841, IEEE 112 B
- Division 2 applications
- NEMA Premium Efficiency
- Class H insulation, 1.25 Service Factor
- Five-year warranty
X$D Ultra® 841 Extra Severe Duty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
X$D Ultra® 841 Extra Severe Duty
- Power: 0.75–300 HP
- Speed: 900–3600 RPM
- Voltage: 460, 575 V
- Frequency: 60 Hz
- TEFC (IP55)
- Frame sizes: 143T–449T
- NEMA, CSA, IEEE 45, meets or exceeds
- IEEE 841, GM 7E-TA, IEEE112B
- Division 2 applications
- NEMA Premium Efficiency
- Class H insulation
- Five-year warranty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
- Power: 40–300 HP
- Speed: 1200–1800 RPM
- Voltage: 230/460, 460, 575 V
- Frequency: 60 Hz
- TEFC (IP55)
- Frame sizes: 143T–449T
- NEMA Design “C”, CSA, IEEE 45, IEEE 112B
- NEMA Premium Efficiency
- Class H insulation
- Five-year warranty
X$D Ultra Explosion Proof Motor
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
X$D Ultra® KGS Plus-High Torque Extra Severe Duty
- Power: 1.5–30 HP
- Speed: 900–3600 RPM
- Voltage: 230/460, 575 V
- Frequency: 60 Hz
- Alternate 50 Hz data on nameplate
- TEFC (IP55)
- Frame sizes: 182T–286T
- NEMA, CSA, IEEE 112B
- NEMA Premium Efficiency
- Class H insulation
- Five-year warranty
A$D Ultra® Adjustable Speed Motor
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
- Power: 1.5–300 HP
- Speed: 1800 RPM
- Voltage: 230/460, 460, 575 V
- Frequency: 60 Hz
- TEFC, TEBC, TENV (IP55)
- Frame sizes: 143TC–449T
- NEMA, IEEE 841, IEEE 112 B
- Premium Efficiency
- Class H insulation
- Five-year warranty
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
X$D Ultra® 661 Heat Exchanger Extra Severe Duty
- Power: 5–75 HP
- Speed: 1800 RPM
- Voltage: 460 V
- Frequency: 60 Hz
- TEFC (IP55)
- Frame sizes: 184T–365T
- NEMA, CSA, exceeds API 661 and IEEE 841,
- IEEE 45, GM 7E-TA, IEEE 112B
- Division 2 application
- NEMA Premium Efficiency
- Class H insulation
- Five-year warranty
Energy $aver®
Energy $aver®
Energy $aver®
- Power: 1–300 HP
- Speed: 1200–3600 RPM
- Voltage: 200, 230/460, 460, 575 V
- Frequency: 60 Hz
- Alternate 50 Hz data on
- nameplate
- ODP
- Frame sizes: 143T–449T
- NEMA, CSA, IEEE 112B
- NEMA Premium Efficiency
- Class F insulation
- Three-year warranty
Energy $aver®
Energy $aver®
Energy $aver®
- Power: 1–250 HP
- Speed: 1200–3600 RPM
- Voltage: 200, 230/460, 460, 575 V
- Frequency: 60 Hz
- Alternate 50 Hz data on
- nameplate
- TEFC (IP55)
- Frame sizes: 143T–449T
- NEMA, CSA, IEEE 112 B
- NEMA Premium Efficiency
- Class F insulation
- Three-year warranty
Energy $aver® and X$D Custom
Quantum™ LMV Severe Duty Low and Medium Voltage Induction
Quantum™ LMV Severe Duty Low and Medium Voltage Induction
- Power: 5–800 HP
- Speed: 900–3600 RPM
- Voltage: 200–4160 V
- Frequency: 50 Hz or 60 Hz
- ODP,TEFC, XP
- Frame sizes: 143T–449T
- NEMA,CSA, IEEE 112B
- Class F insulation
- NEMA Premium Efficiency
- Hundreds of custom features
- available
- Two-year warranty
Quantum™ LMV Severe Duty Low and Medium Voltage Induction
Quantum™ LMV Severe Duty Low and Medium Voltage Induction
Quantum™ LMV Severe Duty Low and Medium Voltage Induction
- Power: 200–2,000 HP
- Speed: 750–3000/900–3600 RPM
- Voltage: up to 6900 V
- Frequency: 50 Hz or 60 Hz
- TEFC Severe Duty (IP55)
- Frame sizes: 509–7011
- NEMA, API 541, API 547, IEEE 841
- NEMA Premium Efficiency where
- applicable
- Class F insulation
- Three-year warranty
AC Induction/IEC
X$D® IEC Extra Severe Duty
QUANTUM™ LMV SEVERE DUTY LOW AND MEDIUM VOLTAGE INDUCTION
X$D Ultra® 841 IEC Extra Severe Duty
- Power: 0.55–220 kW
- Speed: 750–3000/900-3600 RPM
- Voltage/Frequency: 400 V 400/690V,
- 690V/50 Hz
- Voltage/Frequency: 230/460, 460, 575 V,
- 690 V/60 Hz
- TEFC (IP55)
- Frame sizes: 90S–280H
- IEC, IEEE 841, IEEE 45
- IE2 Efficiency
- 1.6 mm/sec (0.063 ips) vibration
- Class H insulation
- Two-year warranty
X$D Ultra® 841 IEC Extra Severe Duty
QUANTUM™ LMV SEVERE DUTY LOW AND MEDIUM VOLTAGE INDUCTION
X$D Ultra® 841 IEC Extra Severe Duty
- Power: 0.55–220 kW
- Speed: 750–3000/900–3600 RPM
- Voltage/Frequency: 200 V, 400 V, 400/690,
- 690 V/50 Hz
- Voltage/Frequency: 230/460, 460, 575,
- 690 V/60 Hz
- TEFC (IP55)
- Frame size: 90S–280H
- IEC, IEEE 841, IEEE 45, ATEX and IEC Exn
- IE3 Efficiency
- Zone II, ABS, GOST-R
- 1.4 mm/sec (0.055 ips) vibration
- Class H insulation
- Five-year warranty
QUANTUM™ LMV SEVERE DUTY LOW AND MEDIUM VOLTAGE INDUCTION
QUANTUM™ LMV SEVERE DUTY LOW AND MEDIUM VOLTAGE INDUCTION
QUANTUM™ LMV SEVERE DUTY LOW AND MEDIUM VOLTAGE INDUCTION
- Power: 150–1500 kW
- Speed: 600–3000/720–3600 RPM
- Voltage: up to 6900 V
- Frequency: 50 Hz or 60 Hz
- TEFC (IP55)
- Frame Sizes: 315 and 450
- IEC designs
- Low noise option
- API 541,API 547, IEEE 841
- IE2 or IE3 Efficiency
- Class F insulation
- Three-year warranty
AC Induction Vertical Motors
Custom Vertical
ValueLine™ VHS Vertical
ValueLine™ VHS Vertical
- Power: 2–800 HP
- Speed: 900–3600 RPM
- Voltage: 200–4160 V
- Frequency: 50 Hz or 60 Hz
- WPI, WPII, TEFC
- Frame sizes: 213–5013
- NEMA, CSA, IEEE 841,
- IEEE, 112B
- Hollow or solid shaft
- High or Premium Efficiency
- Class F insulation
ValueLine™ VHS Vertical
ValueLine™ VHS Vertical
ValueLine™ VHS Vertical
- Power: 5–500 HP
- Speed: 1200–3600 RPM
- Voltage: 230/460 V, 460 V
- (part winding start)
- Frequency: 60 Hz
- De-rated at 50 Hz and noted
- on nameplate
- WPI
- Frame sizes: 213–509
- High Efficiency
- Class F insulation
- Three-year warranty
Pegasus™ MHV Vertical
8200–8900 Frame Vertical
8200–8900 Frame Vertical
- Power: 500–8500 HP (373–6300 kW)
- Speed: 333–1800 RPM
- Voltage: up to 13.8 kV
- Frequency: 50 Hz or 60 Hz
- WPI, WPII, TEAAC, TEWAC
- Frame sizes: PV 500–PV 900
- API 541, IEC, NEMA
8200–8900 Frame Vertical
8200–8900 Frame Vertical
8200–8900 Frame Vertical
- Power: 500–12500 HP (9,000 kW)
- Speed: 360–1800 RPM
- Voltage: up to 13800 V
- Frequency: 50 Hz or 60 Hz
- WPI, WPII, TEAAC, TEWAC
- API 541, IEC, NEMA
AC Induction Custom Motors
509–5013 Frame Low and Medium Voltage
Pegasus™ LMV Medium and High Voltage Induction
Pegasus™ LMV Medium and High Voltage Induction
- Power: 100–800 HP
- Speed: 750–3000/900–3600 RPM
- Voltage: 400–4160 V
- Frequency: 50 Hz or 60 Hz
- NEMA
- ODP, WPI, WII, TEFC, XP
- Frame sizes: 509–5013
- Vertical or horizontal configuration
- High or Premium Efficiency
- Class F insulation
Pegasus™ LMV Medium and High Voltage Induction
Pegasus™ LMV Medium and High Voltage Induction
Pegasus™ LMV Medium and High Voltage Induction
- Power: 500–22000 HP (16000 kW)
- Speed: 900–1200 RPM
- Voltage: up to 13800 V
- Frequency: 50 Hz or 60 Hz
- Frame sizes: 8200–8900
- WPI, WPII, TEAAC, TEWAC
- API 541, 547, NEMA, IEC designs
Pegasus™ MHV Wound Rotor Induction Motor
Pegasus™ LMV Medium and High Voltage Induction
Pegasus™ MHV Wound Rotor Induction Motor
- Power: 1000–10500 HP (750–7830 kW)
- Speed: 900–1200 RPM
- Voltage: 4000–6600 V
- Frequency: 50 Hz or 60 Hz
- WPI, WPII, TEAAC, TEWA
- NEMA frames 8100–8500
- IEC frames 500–710
Direct Current Motors
Permanent Magnet DC Totally Enclosed
Permanent Magnet DC Totally Enclosed
Permanent Magnet DC Totally Enclosed
- Power: 0.25–3 HP
- Speed: 1725, 2500, 1150/1380,
- 1750/2050, 2500/2750 RPM
- Voltage: 90 or 180 VDC field
- Frame size: 56C, 146ATC–412ATC
- C-Face w/bolt on feet
- Provision for tachometer
- Drive capable
- Continuous torque to 5% base
- speed with free-wheeling diode
Kinamatic® II
Permanent Magnet DC Totally Enclosed
Permanent Magnet DC Totally Enclosed
- Power: 1–500 HP
- Speed: 300–3600 RPM
- Armature voltage: 180, 240, 500
- Field voltage: 300/150, 240/120
- DPFG, DPFG-BV, TE,
- Explosion proof
- TREC coils: 365AT–5010AY
- frame
- Two-year warranty
- GE Motors, Motores General Electric México
CD6000-CD6900
Permanent Magnet DC Totally Enclosed
MD Motors and Generators
- Power: 500–2000 HP
- Speed: 300–1750 RPM
- Armature voltage: 500, 600
- Field voltage: 300/150
- DPFG, DPFG-BV, TE
- TREC main and
- commutating coils
MD Motors and Generators
MD Motors and Generators
MD Motors and Generators
- Power: 5–500 HP
- Speed: 340–1025 RPM
- Armature voltage: 230, 460
- Field voltage: 230, 460
- Meets AIST standard
- Split frame design
- Double tapered shaft
- Class H insulation TREC coils
Large DC Motors
MD Motors and Generators
Large DC Motors
- Power: up to 12000 HP (8952 kW)
- Speed: up to 2500 RPM
- Voltage: up to 1200 V
- Enclosure: as required by
- the application
- Standards: NEMA, CSA
Synchronous Motors and Generators
Large AC Synchronous Motors
Large AC Synchronous Motors
Large AC Synchronous Motors
- Power: 1000–100000 HP (75000 kW)
- Speed: 150–1800 RPM
- Voltage: up to 15000 V
- Frequency: 50 Hz and 60 Hz
- Enclosures: all types
- Standards: NEMA, CSA, IEEE, IEC, API 546
Quadramatic™
Large AC Synchronous Motors
Large AC Synchronous Motors
- Power: up to 30000 HP (up to 22000 kW)
- Speed: 166 RPM–240 RPM
- Voltage: up to 15000 V
- Frequency: 50 Hz or 60 Hz
- Enclosures: ODP, WPI
- Standards: NEMA, CSA
Series 9000 – RCM
Large AC Synchronous Motors
Steam and Gas Turbine Generators
- Power: 3000–22000 HP
- Speed: 167–428 RPM
- Voltage: up to 13800 V
- Frequency: 50 Hz and 60 Hz
- Open, WPI, WPII, TEWAC, TEFV, TEAAC
- Frame size: two sizes – 800 mm
- shaft height
- API 546, NEMA, IEC, IEEE
Steam and Gas Turbine Generators
Steam and Gas Turbine Generators
Steam and Gas Turbine Generators
- Power: up to 75000 kVA
- Speed: 900–1800 RPM
- Voltage: up to 13800 V
- Frequency: 50 Hz and 60 Hz
- Enclosures: all types
- Standards: NEMA, CSA, IEEE, IEC, API
Synchronous Hydro Generators
Steam and Gas Turbine Generators
Synchronous Hydro Generators
Horizontal and Vertical Applications:
- Power: 2000–37500 kVA
- Speed: 150–900 RPM
- Voltage: up to 13800 V
- Frequency 50 Hz and 60 Hz
- Enclosures IDP, TEWAC
- Standards: ANSI, CSA, IEEE 115, NEMA MG-1, IEC 60034
general electric querétaro
general electric méxico
general electric toluca
general electric nuevo león
general electric apodaca
general electric culiacan
general electric jalisco
general electric puebla
general electric tijuana
general electric ciudad juarez
general electric zapopan
general electric chihuahua
general electric merida
general electric cancun
general electric saltillo
general electric aguascalientes
general electric hermosillo
general electric san luis potosi
general electric mexicali
general electric torreon
general electric bajío
general electric monterrey
general electric guadalajara
general electric guanajuato
general electric cdmx
general electric estado de méxico
general electric edo mex
productos general electric méxico
artículos general electric méxico
somos distribuidores autorizados general electric méxico
somos distribuidores oficiales general electric méxico
productos GE méxico
artículos GE méxico
somos distribuidores autorizados GE méxico
somos distribuidores oficiales GE méxico
distribuidor oficial general electric méxico
distribuidor oficial GE méxico
distribuidor general electric querétaro
distribuidor general electric bajío
distribuidor general electric toluca
distribuidor general electric nuevo leon
distribuidor general electric jalisco
distribuidor general electric monterrey
distribuidor general electric guadalajara
distribuidor general electric guanajuato
distribuidor general electric cdmx
distribuidor general electric estado de méxico
distribuidor general electric edo mex
distribuidor general electric méxico
distribuidor general electric puebla
distribuidor general electric tijuana
distribuidor general electric ciudad juarez
distribuidor general electric zapopan
distribuidor general electric chihuahua
distribuidor general electric merida
distribuidor general electric cancun
distribuidor general electric saltillo
distribuidor general electric aguascalientes
distribuidor general electric hermosillo
distribuidor general electric san luis potosi
distribuidor general electric mexicali
distribuidor general electric torreon
distribuidor general electric apodaca
distribuidor general electric culiacan
distribuidor general electric mexico
distribuidores general electric querétaro
distribuidores general electric bajío
distribuidores general electric toluca
distribuidores general electric nuevo leon
distribuidores general electric jalisco
distribuidores general electric monterrey
distribuidores general electric guadalajara
distribuidores general electric guanajuato
distribuidores general electric cdmx
distribuidores general electric estado de méxico
distribuidores general electric edo mex
distribuidores general electric méxico
distribuidores general electric puebla
distribuidores general electric tijuana
distribuidores general electric ciudad juarez
distribuidores general electric zapopan
distribuidores general electric chihuahua
distribuidores general electric merida
distribuidores general electric cancun
distribuidores general electric saltillo
distribuidores general electric aguascalientes
distribuidores general electric hermosillo
distribuidores general electric san luis potosi
distribuidores general electric mexicali
distribuidores general electric torreon
distribuidores general electric apodaca
distribuidores general electric culiacan
distribuidores general electric mexico
distribuidor general electric
distribuidor autorizado general electric
distribuidor autorizado general electric méxico
distribuidores general electric
distribuidores general electric méxico
distribuidores autorizados general electric
distribuidores autorizados general electric méxico
ge querétaro
ge méxico
ge toluca
ge nuevo león
ge apodaca
ge culiacan
ge jalisco
ge puebla
ge tijuana
ge ciudad juarez
ge zapopan
ge chihuahua
ge merida
ge cancun
ge saltillo
ge aguascalientes
ge hermosillo
ge san luis potosi
ge mexicali
ge torreon
ge bajío
ge monterrey
ge guadalajara
ge guanajuato
ge cdmx
ge estado de méxico
ge edo mex
distribuidor ge querétaro
distribuidor ge bajío
distribuidor ge toluca
distribuidor ge nuevo leon
distribuidor ge jalisco
distribuidor ge monterrey
distribuidor ge guadalajara
distribuidor ge guanajuato
distribuidor ge cdmx
distribuidor ge estado de méxico
distribuidor ge edo mex
distribuidor ge méxico
distribuidor ge puebla
distribuidor ge tijuana
distribuidor ge ciudad juarez
distribuidor ge zapopan
distribuidor ge chihuahua
distribuidor ge merida
distribuidor ge cancun
distribuidor ge saltillo
distribuidor ge aguascalientes
distribuidor ge hermosillo
distribuidor ge san luis potosi
distribuidor ge mexicali
distribuidor ge torreon
distribuidor ge apodaca
distribuidor ge culiacan
distribuidor ge mexico
distribuidores ge querétaro
distribuidores ge bajío
distribuidores ge toluca
distribuidores ge nuevo leon
distribuidores ge jalisco
distribuidores ge monterrey
distribuidores ge guadalajara
distribuidores ge guanajuato
distribuidores ge cdmx
distribuidores ge estado de méxico
distribuidores ge edo mex
distribuidores ge méxico
distribuidores ge puebla
distribuidores ge tijuana
distribuidores ge ciudad juarez
distribuidores ge zapopan
distribuidores ge chihuahua
distribuidores ge merida
distribuidores ge cancun
distribuidores ge saltillo
distribuidores ge aguascalientes
distribuidores ge hermosillo
distribuidores ge san luis potosi
distribuidores ge mexicali
distribuidores ge torreon
distribuidores ge apodaca
distribuidores ge culiacan
distribuidores ge mexico
distribuidor ge
distribuidor autorizado ge
distribuidor autorizado ge méxico
distribuidores ge
distribuidores ge méxico
distribuidores autorizados ge
distribuidores autorizados ge méxico
